APC-8E-250 - Mean Well LED Driver APC-8E-250 8W 250mA
Constant CurrentFully isolated plastic caseProtections:Â Short circuitOther features:Small and compact sizeNo load power consumption <0.5WIP42 designClass II power unit, no FGCooling by free air convectionPF>0.5100% full load burn-in testLow cost, High reliability2 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 8 Output Current 250mA Dimmable (Type) No Output Voltage Range (V) 16~32 Dimensions 60 x 30 x 23.5 EMC Standards EN55015, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 ; light industry level (surge 2KV), Criteria A Input Voltage 180~264VAC; 254~370VDC Safety Standards Design refer to UL8750, CSA C22.2 No.250.0-08;EN60950-1, EN61347-1, EN61347-2-13 Output Voltage Options Single Working Temperature -40~+80°C PDF Datasheet APC-8E-spec.pdf
More Information Manufacturer Mean Well Output Wattage (W) 8 Output Current 250mA Dimmable (Type) No Output Voltage Range (V) 16~32 Dimensions 60 x 30 x 23.5 EMC Standards EN55015, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 ; light industry level (surge 2KV), Criteria A Input Voltage 180~264VAC; 254~370VDC Safety Standards Design refer to UL8750, CSA C22.2 No.250.0-08;EN60950-1, EN61347-1, EN61347-2-13 Output Voltage Options Single Working Temperature -40~+80°C PDF Datasheet APC-8E-spec.pdf
$12.12
APC-8E-250 - Mean Well LED Driver APC-8E-250 8W 250mAâ
$12.12
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Constant CurrentFully isolated plastic caseProtections:Â Short circuitOther features:Small and compact sizeNo load power consumption <0.5WIP42 designClass II power unit, no FGCooling by free air convectionPF>0.5100% full load burn-in testLow cost, High reliability2 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 8 Output Current 250mA Dimmable (Type) No Output Voltage Range (V) 16~32 Dimensions 60 x 30 x 23.5 EMC Standards EN55015, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 ; light industry level (surge 2KV), Criteria A Input Voltage 180~264VAC; 254~370VDC Safety Standards Design refer to UL8750, CSA C22.2 No.250.0-08;EN60950-1, EN61347-1, EN61347-2-13 Output Voltage Options Single Working Temperature -40~+80°C PDF Datasheet APC-8E-spec.pdf
More Information Manufacturer Mean Well Output Wattage (W) 8 Output Current 250mA Dimmable (Type) No Output Voltage Range (V) 16~32 Dimensions 60 x 30 x 23.5 EMC Standards EN55015, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 ; light industry level (surge 2KV), Criteria A Input Voltage 180~264VAC; 254~370VDC Safety Standards Design refer to UL8750, CSA C22.2 No.250.0-08;EN60950-1, EN61347-1, EN61347-2-13 Output Voltage Options Single Working Temperature -40~+80°C PDF Datasheet APC-8E-spec.pdf
